AN565AC524H4|SET SCREW

AN565AC524H4

SET SCREW

  • Unit of Measure: EA
  • ECCN: EAR99
  • Weight: 0.01 Pounds
  • Dimensions : 0.2 (L) x 0.25 (W) x 0.25 (H) Inches
  • Packaged Weight: 0.01 lbs
  • Packaged Dimensions : 3.8 (L) x 3 (W) x 0.3 (H) in

DESCRIPTION

Military Standard Set Screw

  • Headless
  • Fine Threads
  • Socket
  • Thread Class: 3A
  • Point Style: Flat
  • Material: Corrosion Resisting Steel
  • Finish: Passivated
  • Major Diameter: 0.3125 in.
  • Threads Per Inch (TPI): 24
  • Length: 0.25 in.
  • Industry Standard Specification: AIA/NAS NASM565

Each delivered OEM part will meet the original manufacturer’s specification or, if the part is not an OEM part, it will meet or exceed the original manufacturer’s specification. Please contact metadata@txtav.com if part information appears to be incorrect.
 In-stock and ready to ship!
