P526-03OHKIT

OVERHAUL KIT

Unit of Measure: EA
Part Type: Proprietary

DESCRIPTION

McCauley Propeller C526-03 Overhaul Kit

This propeller overhaul kit contains all mandatory replacement parts from the applicable propeller overhaul manual
Contains:
- O-Ring (Qty 2) - A1633-11
- O-Ring (Qty 3) - A1633-56
- O-Ring (Qty 2) - A1633-58
- Screw (Qty 6) - A1635-112
- Screw (Qty 6) - A1635-159
- Screw (Qty 2) - A1635-40
- Screw (Qty 1) - A1635-54
- Screw (Qty 12) - A1635-76
- Washer (Qty 6) - A-1638-10
- Washer (Qty 4) - A-1638-18
- Washer (Qty 10) - A-1638-26
- Nut (Qty 4) - A1639-23
- Seal (Qty 1) - A-1750-2
- Seal Washer (Qty 3) - A-1750-4
- Decal-Propeller Install (Qty 1) - A-2230
- Pin (Qty 6) - A3150-1
- Pipe Plug (Qty 1) - A-4714
- Decal (Qty 1) - B4862-561
- Nut (Qty 6) - B-5478
- Decal (Qty 1) - B-7366
- Stud (Qty 6) - B-7541
- Gasket (Qty 1) - C7361
- Gasket (Qty 1) - C-7362
- C500-01 Overhaul Kit (Qty 1):
  - O-Ring (Qty 1) – A1633-23
  - O-Ring (Qty 1) – A1633-39
  - O-Ring (Qty 1) - A1633-9
  - Ball Bearing (Qty 96) – A1634-9
  - Retaining Ring (Qty 1) – A1636-16
  - Retaining Ring (Qty 1) – A-1636-7
  - Retaining Ring (Qty 6) – A1636-9
  - Washer (Qty 1) – A-1638-7
  - Nut (Qty 3) – A-1639-4
  - Pin (Qty 2) – A1896
  - Decal (Qty 1) – A-2501
  - Pin Roll (Qty 4) – A3150-17
  - Pin Roll (Qty 1) – A3150-3
  - Bearing (Qty 3) – A-3483
  - Washer (Qty 1) – A-4065
  - Bearing (Qty 3) – A-4564
  - Spring Assembly (Qty 2) – B-4789
  - Separator (Qty 96) – B5223
  - Decal-Trademark (Qty 3) – B6172

Each delivered OEM part will meet the original manufacturer’s specification or, if the part is not an OEM part, it will meet or exceed the original manufacturer’s specification. Please contact metadata@txtav.com if part information appears to be incorrect.
